2013 CORVETTE
CORVETTE & GRAND SPORT
ENGINE
6.2L V-8 LS3
Displacement (cu in / cc) - 376 / 6162
Bore & stroke (in / mm) - 4.06 x 3.62 / 103.25 x 92
Block material - cast aluminium
Cylinder head material - cast aluminium
Valvetrain - overhead valve, two valves per cylinder
Fuel delivery - SFI (sequential fuel injection)
Lubrication system:
Wet sump (Corvette and Grand Sport with automatic)
Dry sump (Grand Sport coupe with manual)
Compression ratio - 10.7:1
Horsepower (hp / kW @ rpm):
430 / 321 @ 5900 w/ std. exhaust
436 / 325 @ 5900 w/ opt. exhaust
Torque(lb-ft / Nm @ rpm):
424 / 575 @ 4600 w/ std. exhaust
428 / 580 @ 4600 w/ opt. exhaust
Recommended fuel - premium recommended, not required
TRANSMISSIONS
Six-speed manual, or Six-speed paddle-shift automatic
Final drive ratio:
Six-speed manual - 3.42
Six-speed paddle-shift automatic - 2.56
Six-speed paddle-shift automatic - 2.73 (Grand Sport)
CHASSIS/SUSPENSION
Corvette
Front - short/long arm (SLA) double wishbone, cast aluminium upper and lower control arms, transverse-mounted composite leaf spring, monotube shock absorber
Rear - short/long arm (SLA) double wishbone, cast aluminium upper and lower control arms, transverse-mounted composite leaf spring, monotube shock absorberTraction control - electronic traction control; Active Handlin
Corvette Grand Sport
Front - short/long arm (SLA) double wishbone, cast aluminium upper and lower control arms, transverse-mounted composite leaf spring, monotube shock absorber
Rear - short/long arm (SLA) double wishbone, cast aluminium upper and lower control arms, transverse-mounted composite leaf spring, monotube shock absorber
Traction control - electronic traction control; Active Handling
BRAKES
Corvette
Type - front and rear power-assisted disc with ABS
Rotor diameter x thickness (in / mm):
Front: 12.8 x 1.26 / 325 x 32 (std.); 13.4 x 1.26 / 340 x 32 (w/ Magnetic Ride Control)
Rear: 12 x 1 / 305 x 26; (std.); 13 x 1 / 330 x 26 (w/ Magnetic Ride Control)
Brake swept area (sq in / mm):
Front: 274 / 1768
Rear: 200 / 1290
Corvette Grand Sport
Type - front and rear power-assisted disc with ABS with six-piston front and four-piston rear calipers, cross-drilled rotors
Rotor diameter x thickness (in / mm):
Front: 14 x 1.3 / 355 x 32
Rear: 13.4 x 1 / 340 x 26
Brake swept area (sq in / mm):
Front: 309 / 1994
Rear: 269 / 1735
WHEELS/TYRES
Corvette
Wheel size:
Front: 18-inch x 8.5-inch
Rear: 19-inch x 10-inch
Tyres (front) - P245/40ZR18 Goodyear Eagle F1 run flat
Tyres (rear) - P285/35ZR19 Goodyear Eagle F1 run flat
Corvette Grand Sport
Wheel size:
Front: 18-inch x 9.5-inch
Rear: 19-inch x 12-inch
Tyres (front):
P275/35ZR18 Goodyear Eagle F1 Supercar run flat (std.)
P275/35ZR18 Goodyear Eagle F1 Supercar GEN2 run flat (avail.)
Tyres (rear):
P325/30ZR19 Goodyear Eagle F1 Supercar run flat (std.)
P325/30ZR19 Goodyear Eagle F1 Supercar GEN2 run flat (avail.)
DIMENSIONS - EXTERIOR
Corvette
Wheelbase (in / mm) - 105.7 / 2685
Overall length (in / mm) - 174.6 / 4435
Overall width (in / mm) - 72.6 / 1844
Overall height (in / mm) - 49 / 1244
Curb weight (lb / kg):
3208 / 1455 (coupe)
3221 / 1461 (convertible)
Weight distribution (% front / rear) - 51 / 49
Corvette Grand Sport
Wheelbase (in / mm) - 105.7 / 2685
Overall length (in / mm) - 175.6 / 4460
Overall width (in / mm) - 75.9 / 1928
Overall height (in / mm) - 48.7 / 1236
Curb weight (lb / kg):
3311 / 1502 (coupe)
3289 / 1492 (convertible)
Weight distribution (% front / rear) - 51 / 49
DIMENSIONS - INTERIOR
Seating capacity - 2
Interior volume (cu ft / L) - 52 / 1475
Headroom (in / mm) - 38 / 962
Leg room (in / mm) - 43 / 1092
Shoulder room (in / mm) - 55 / 1397
Hip room (in / mm) - 54 / 1371
CORVETTE Z06
ENGINE
7.0L V-8 (LS7)
Displacement (cu in / cc) - 427 / 7008
Bore & stroke (in / mm) - 4.125 x 4 / 104.8 x 101.6
Block material - cast aluminiumCylinder head material - cast aluminium
Valvetrain - overhead valve, two valves per cylinder
Fuel delivery - SFI (sequential fuel injection)
Compression ratio - 11.0:1
Horsepower (hp / kW @ rpm) - 505 / 377 @ 6300 (SAE certified)
Torque (lb-ft / Nm @ rpm) - 470 / 637 @ 4800 (SAE certified)
Recommended fuel - premium required
TRANSMISSION
Six-speed manual
Gear ratios:
First - 2.66
Second - 1.78
Third - 1.30
Fourth - 1.00
Fifth - 0.74
Sixth - 0.50
Reverse - 2.90
Final drive ratio - 3.42
CHASSIS/SUSPENSION
Front - short/long arm (SLA) double wishbone, cast aluminium upper and lower control arms, transverse-mounted composite leaf spring, monotube shock absorber; Magnetic Ride Control w/ Z07 pkg.
Rear - short/long arm (SLA) double wishbone, cast aluminium upper and lower control arms, transverse-mounted composite leaf spring, monotube shock absorber; Magnetic Ride Control w/ Z07 pkg.
Traction control - electronic traction control; Active Handling
BRAKES
Type - front and rear power-assisted disc with ABS with six-piston front and four-piston rear calipers, cross-drilled rotors; ceramic rotors w/ Z07 pkg.
Rotor diameter x thickness (in / mm):
Front: 14 x 1.3 / 355 x 32
Rear: 13.4 x 1 / 340 x 26
Brake swept area (sq in / mm):
Front: 309 / 1994
Rear: 269 / 1735
WHEELS/TYRES
Wheel size:
Front - 18-inch x 9.5-inch (std); 19-inch x 10-inch (w/ F55 Magnetic Ride Control)
Rear - 19-inch x 12-inch (std); 20-inch x 12-inch (w/ F55 Magnetic Ride Control)
Tyres:
Front - 275/35ZR18 (std.); 285/30ZR19 (w/ F55 pkg.)
Rear - 325/30ZR19 (std.); 335/25ZR20 (w/ F55 pkg.)
DIMENSIONS
Exterior
Wheelbase (in / mm) - 105.7 / 2685
Overall length (in / mm) - 175.6 / 4460
Overall width (in / mm) - 75.9 / 1928
Overall height (in / mm) - 48.7 / 1236
Curb weight (lb / kg) - 3199 / 1451
Weight distribution (% front / rear) - 50 / 50
Interior
Seating capacity - 2
Interior volume (cu ft / L) - 52 / 1475
Headroom (in / mm) - 38 / 962
Legroom (in / mm) - 43 / 1092
Shoulder room (in / mm) - 55 / 1397
Hip room (in / mm) - 54 / 1371
CORVETTE ZR1
ENGINE
6.2L Supercharged V-8 (LS9)
Displacement (cu in / cc) - 376 / 6162
Bore & stroke (in / mm) - 4.06 x 3.62 / 103.25 x 92
Block material - cast aluminium
Cylinder head material - cast aluminium
Valvetrain - overhead valve, two valves per cylinder
Fuel delivery - SFI (sequential fuel injection)
Compression ratio - 9.1:1
Horsepower (hp / kW) - 638 / 476 @ 6500 (SAE certified)
Torque (lb-ft / Nm) - 604 / 819 @ 3800 (SAE certified)
Recommended fuel - premium required
TRANSMISSION
Tremec TR6060 close-ratio six-speed manual
Gear ratios:
First - 2.29
Second - 1.61
Third - 1.21
Fourth - 1.00
Fifth - 0.82
Sixth - 0.68
Reverse - 3.11
Final drive ratio - 3.42
CHASSIS/SUSPENSION
Front - short/long arm (SLA) double wishbone, cast aluminium upper and lower control arms, transverse-mounted composite leaf spring, monotube shock absorber
Rear - short/long arm (SLA) double wishbone, cast aluminium upper and lower control arms, transverse-mounted composite leaf spring, monotube shock absorber
Traction control - electronic traction control; active handling (Magnetic Selective Ride Control)
BRAKES
Type - front and rear power-assisted carbon-ceramic disc with 6-piston front and four-piston rear calipers, cross-drilled rotors; ABS std.
Rotor diameter (in / mm):
Front: 15.5 / 394
Rear: 15 / 380
Brake swept area (sq in / mm):
Front: 355 / 2290
Rear: 309 / 1994
WHEELS/TYRES
Wheel size:
Front - 19-inch x 10-inch
Rear - 20-inch x 12-inch
Tyres - Michelin Pilot Sport 2
Front: P285/30ZR19
Rear: P335/25ZR20
DIMENSIONS
Exterior
Wheelbase (in / mm) - 105.7 / 2685
Overall length (in / mm) - 176.2 / 4476
Overall width (in / mm) - 75.9 / 1929
Overall height (in / mm) - 48.7 / 1236
Curb weight (lb / kg) - 3353 / 1521
Weight distribution (% front / rear) - 51 / 49
Interior
Seating capacity - 2
Interior volume (cu ft / L) - 52 / 1475
Headroom (in / mm) - 38 / 962
Legroom (in / mm) - 43 / 1092
Shoulder room (in / mm) - 55 / 1397
Hip room (in / mm) - 54 / 1371
