ENGINES
2.0L I-4 DOHC VVT DI Turbocharged
Horsepower (hp / kW @ rpm) - 275 / 205 @ 5600 (SAE certified)
Torque (lb.-ft. / Nm @ rpm) - 295 / 400 @ 3000-4500 (SAE certified)
3.6L V-6 DOHC VVT DI (includes cylinder deactivation with automatic transmission)
Horsepower (hp / kW @ rpm) - 335 / 250 @ 6800 (SAE certified)
Torque (lb.-ft. / Nm @ rpm) - 284 / 383 @ 5300 (SAE certified)
TRANSMISSION & AXLE
TREMEC six-speed manual (std.), or Hydra-Matic 8L45 eight-speed automatic (avail.)
Final Drive Ratio - 3.27 (2.0L Turbo or 3.6L with manual), 2.77 (3.6L with automatic)
CHASSIS & SUSPENSION
Front Suspension - MacPherson-type strut with dual lower ball joints, twin-tube struts and direct-acting stabilizer bar
Rear Suspension - Independent five-link with twin-tube shocks and direct-acting stabilizer bar
Steering Type - ZF rack-mounted electric, power-assisted and variable ratio rack-and-pinion
Turning Circle (ft. / m) - 38.1 / 11.6
Brake Type - Four-wheel disc with four-channel ABS
Brake Rotor Size (in / mm):
Front - 12.6 / 321 vented with four-piston fixed calipers (std.); 13.6 / 345 vented with four-piston fixed calipers with available Brembo system
Rear - 12.4 / 315 vented, with single-piston sliding calipers
WHEELS/TYRES
Wheel Size:
18-in. aluminium (std.)
20-in. aluminium (avail. and included with RS package and 50th Anniversary Edition)
Tyre Size:
P245/50R18 Goodyear Eagle Sport A/S all-season
P245/40R20 Goodyear Eagle F1 Asymmetric A/S EMA all-season run-flat
EXTERIOR DIMENSIONS
Wheelbase (in. / mm) - 110.7 / 2811
Overall Length (in. / mm) - 188.3 / 4784
Overall Width (in. / mm) - 74.7 / 1897
Overall Height (in. / mm) - 53.1 / 1348
Track (in. mm):
Front: 62.5 / 1588
Rear: 63.7 / 1618
INTERIOR DIMENSIONS
Headroom (in / mm):
38.5 / 978 (front – coupe)
38.5 / 978 (front – conv.)
33.5 / 852 (rear – coupe)
33.4 / 850 (rear – conv.)
Legroom (in. / mm):
43.9 / 1115 (front)
29.9 / 759 (rear)
Shoulder Room (in. / mm) - 55 / 1398 (front)
Hip Room (in. / mm) - 54.5 / 1386 (front)
WEIGHTS & CAPACITIES
Curb Weight (lb. / kg):
3354 / 1521 (2.0T manual – coupe)
3334 / 1512 (2.0T automatic – coupe)
3627 / 1645 (2.0T manual – conv.)
3607 / 1636 (2.0T automatic – conv.)
3463 / 1570 (3.6L manual – coupe)
3454 / 1566 (3.6L automatic – coupe)
3734 / 1693 (3.6L manual – conv.)
3725 / 1689 (3.6L automatic – conv.)
ENGINE
6.2L LT1 V-8, VVT with Direct Injection (cylinder deactivation with automatic transmission)
Horsepower (hp / kW @ rpm) - 455 / 339 @ 6000 (SAE certified)
Torque (lb.-ft. / Nm @ rpm) - 455 / 614 @ 4400 (SAE certified)
TRANSMISSION & AXLE
TREMEC six-speed manual with Active Rev Match (standard)
Hydra-Matic 8L45 eight-speed automatic (available)
Final Drive Ratio - 3.73 (manual), 2.77 (automatic)
CHASSIS & SUSPENSION
Front Suspension - MacPherson-type strut with dual lower ball joints, twin-tube struts and direct-acting stabilizer bar; avail. monotube Magnetic Ride Control
Rear Suspension - Independent five-link with twin-tube shocks and direct-acting stabilizer bar; avail. monotube Magnetic Ride ControlSteering Type - ZF rack-mounted electric, power-assisted and variable ratio rack-and-pinion
Turning Circle (ft. / m) - 38.1 / 11.6
Brake Type - Four-wheel disc with four-channel ABS
Brake Rotor Size (in / mm):
Front: 13.6 / 345 vented with four-piston fixed calipers
Rear: 13.3 / 339 vented with four-piston fixed calipers
WHEELS/TYRES
Wheel Size:
20-in. x 8.5-in. aluminium (front)
20-in. x 9.5-in. aluminium (rear)
Tyre Size:
P245/40R20 Goodyear Eagle F1 Asymmetric 3 summer-only run-flat
P275/35R20 Goodyear Eagle F1 Asymmetric 3 summer-only run-flat
EXTERIOR DIMENSIONS
Wheelbase (in. / mm) - 110.7 / 2811
Overall Length (in. / mm) - 188.3 / 4784
Overall Width (in. / mm) - 74.7 / 1897
Overall Height (in. / mm) - 53.1 / 1348
Track (in. mm):
Front: 63 / 1600
Rear: 62.9 / 1598
INTERIOR DIMENSIONS
Headroom (in / mm):
38.5 / 978 (front – coupe)
38.5 / 978 (front – conv.)
33.5 / 852 (rear – coupe)
33.4 / 850 (rear – conv.)
Legroom (in. / mm):
43.9 / 1115 (front)
29.9 / 759 (rear)
Shoulder Room (in. / mm) - 55 / 1398 (front)
Hip Room (in. / mm) - 54.5 / 1386 (front)
WEIGHTS & CAPACITIES
Curb Weight (lb. / kg):
3685 / 1671 (manual – coupe)
3697 / 1697 (automatic – coupe)
3932 / 1783 (manual – conv.)
3943 / 1788 (automatic – conv.)
ENGINE
6.2L LT4 Supercharged V-8, VVT with Direct Injection
Horsepower (hp / kW @ rpm) - 650 / 485 @ 6400 (SAE certified)
Torque(lb.-ft. / Nm @ rpm) - 650 / 868 @ 3600 (SAE certified)
TRANSMISSION & AXLE
TREMEC six-speed manual with Active Rev Match (with 1LE-specific top gear ratio)Final Drive Ratio - 3.73
CHASSIS & SUSPENSION
Front Suspension - Strut-type with Multimatic DSSV dampers, dual lower ball joints and direct-acting stabilizer bar; adjustable camber plates, hard-mounted upper struts and hard-mounted front suspension
Rear Suspension - Independent five-link with Multimatic DSSV dampers and three-way adjustable stabilizer bar; solid rear cradle mountsSteering Type - ZF rack-mounted electric, power-assisted and variable ratio rack-and-pinion
Turning Circle (ft. / m) - 38.7 / 11.8
Brake Type - Four-wheel disc with four-channel ABS
Brake Rotor Size (in / mm):
Front - 15.35 / 390 two-piece rotors with six-piston monobloc calipers
Rear - 14.4 / 365 vented, with four-piston fixed calipers
WHEELS/TYRES
Wheel Size:
19-in. x 11-in. forged aluminum (front)
19-in. x 12-in. forged aluminum (rear)
Tyre Size:
Front: P305/30ZR19 Goodyear Eagle F1 Supercar 3R
Rear: P325/30ZR19 Goodyear Eagle F1 Supercar 3R
EXTERIOR DIMENSIONS
Wheelbase (in. / mm) - 110.7 / 2811
Overall Length (in. / mm) - 188.3 / 4784
Overall Width (in. / mm) - 74.7 / 1897
Overall Height (in. / mm) - 52 / 1320
Track (in. mm):
Front: 64.1 / 1628
Rear: 62.8 / 1595
INTERIOR DIMENSIONS
Headroom (in / mm):
38.5 / 978 (front)
33.5 / 852 (rear)
Legroom (in. / mm):
43.9 / 1115 (front)
29.9 / 759 (rear)
Shoulder Room (in. / mm) - 55 / 1398 (front)
Hip Room (in. / mm) - 54.5 / 1386 (front)
WEIGHTS & CAPACITIES
Curb Weight (lb. / kg) - 3820 / 1733 (est.)
EPA passenger volume (cu. ft. / L) - 93 / 2633
Cargo volume (cu. ft. / L) - 9.1 / 257
