ENGINE: 8.4L V10
Type and Description - 10-cylinder, 90-degree V-type, liquid-cooled
Displacement - 8.4 litre (510 cu. in.)
Bore x Stroke - 4.055 x 3.96 (103 x 100.6)
Valve System - OHV, Variable-valve Timing (VVT), 20 valves, roller-type hydraulic lifters
Fuel Injection - Sequential, multi-port, electronic
Construction - Aluminium alloy block with cast-iron liners, aluminium-alloy heads
Compression Ratio - 10.2:1
Power (SAE net) - 600 bhp (450 kW) @ 6,100 rpm (71 bhp/L)
Torque (SAE net) - 560 lb.-ft. (760 N•m @ 5,000 rpm)
Max. Engine Speed - 6,250 rpm
Fuel Requirement - Unleaded premium—91 Octane (R+M)/2
Oil Capacity (with Filters) - 11 qt. (10.4L)
Coolant Capacity - 16 qt. (15L)
Emission Controls - Four three-way catalytic converters, heated oxygen sensors, engine internal features
EPA Fuel Economy (City/Hwy) - 13/22
ELECTRICAL SYSTEM
Alternator - 180-amp high-speed
Battery - Leak-resistant, maintenance-free, 600 CCA
Radio - AM/FM/CD radio with MP3 play capability features 310-watt RMS audio amplifier and seven speakers. Optional navigation packaged with SIRIUS Satellite Radio
TRANSMISSION: MANUAL SIX-SPEED OVERDRIVE
Description - Synchronised in all gears, electronic 1-4 skip-shift and reverse lockout mechanisms, new short-throw shifter on ACR
Gear Ratios:
1st - 2.66
2nd - 1.82
3rd - 1.30
4th - 1.00
5th - 0.80
6th - 0.50
Axle Ratio - 3.07
Overall Top-gear - 1.50
FINAL DRIVE
Description - Frame-mounted hypoid bevel gear with GKN ViscoLok speed-sensing limited-slip differential
DIMENSIONS AND CAPACITIES (a)
Wheelbase - 98.8 (2510)
Track, Front - 61.6 (1565)
Track, Rear - 60.9 (1547)
Overall Length - 175.6 (4459)
Overall Width (at sills) - 75.2 (1911)
Overall Height - 47.6 (1210)
Ground Clearance - 5.125 (130)
Curb Weight:
3,454 lbs. (1567 kg) Coupe
3,441 lbs. (1561 kg) Roadster
3,408 lbs. (1552 kg) ACR Coupe
3,366 lbs. (1533 kg) ACR Hard Core Coupe
Weight Distribution (F/R) - 49.6/50.4
Frontal Area - 19.3 sq. ft. (1.79 sq. m)
Drag Coefficient:
0.42 (top down)
0.38 (top up) Roadster;
0.38 Coupe
Fuel-Tank Capacity - 16.0 gal. (70L)
(a) All dimensions measured with two passengers.
ACCOMMODATION
Seating Capacity - 2
Head Room - 36.5 (926)
Leg Room - 42.4 (1077)
Shoulder Room - 54.1 (1375)
BODY
Layout - Longitudinal front engine, rear-wheel drive
Construction - Backbone tubular space frame with separate cowl structure. SMC and RIM body panels, aluminium sills, RIM front and rear fascias with composite impact beams
ACR AERODYNAMICS
Front - Carbon fiber “fanged” splitter with rub strips; splitter extension; carbon dive planes
Rear - Carbon fiber wing with seven-position adjustable stanchions
Downforce @ 150 mph (high down force setup) - 1,000 lbs.
SUSPENSION
Type - Four-wheel independent with high-performance aluminium control arms and knuckles and lightweight coil-over shock absorbers
Front - Cast-aluminium unequal-length upper and lower “A” arms, coil springs, low- pressure gas-charged shock absorbers, stabiliser bar
Rear - Cast-aluminium unequal-length upper and lower “A” arms, toe-control links, coil springs, low-pressure gas-charged shock absorbers, stabiliser bar
ACR SUSPENSION
Type - Four-wheel independent with high-performance aluminium control arms and knuckles, KW Suspensions with two-way adjustable competition coil-over shock absorbers with remote reservoir
Front - Cast-aluminium unequal-length upper and lower “A” arms, high-rate coil springs, gas-charged two-way adjustable monotube shock absorbers, high- rate stabiliser bar
Rear - Cast-aluminium unequal-length upper and lower “A” arms, toe-control links, high-rate coil springs, gas-charged two-way adjustable monotube shock absorbers, stabiliser bar
STEERING
Type - Power-assisted rack-and-pinion
Overall Ratio - 16.7:1
Turning Diameter (curb-to-curb) - 40.5 ft. (12.34 m)
Steering Turns (lock-to-lock) - 2.4
TYRES
Front (Standard on Roadster and Coupe):
Size and Type - P275/35ZR18
Manufacturer and Model - Michelin® Pilot® Sport PS2 with low-pressure sensors in valve stems
Rear (Standard on Roadster and Coupe):
Size and Type - P345/30ZR19
Manufacturer and Model - Michelin® Pilot® Sport PS2 with low-pressure sensors in valve stems
Front (Standard on ACR):
Size and Type - P295/30ZR18
Manufacturer and Model - Michelin Pilot Sport Cup with low-pressure sensors in valve stems
Rear (Standard on ACR):
Size and Type - P345/30ZR19
Manufacturer and Model - Michelin Pilot Sport Cup with low-pressure sensors in valve stems
WHEELS
Type and Material - Forged aluminium, Roadster and Coupe Lightweight forged aluminium “Sidewinder,” ACR
Size - 18.0 x 10.0—front, 19.0 x 13.0—rear
BRAKES
Front — Size and Type (Roadster and Coupe) - 14.0 x 1.26 (355.0 x 32.0) vented disc, with Brembo 44/40 opposing piston calipers
Rear — Size and Type (Roadster and Coupe) - 14.0 x 1.26 (355.0 x 32.0) vented disc, with Brembo 42/38 dual opposing calipers
Front — Size and Type (ACR) - 14.0 x 1.26 (355.0 x 32.0) vented disc, with Brembo 44/40 opposing piston calipers, curved fin vented StopTech two-piece slotted rotors
Rear — Size and Type (ACR) - 14.0 x 1.26 (355.0 x 32.0) vented disc, with Brembo 42/38 dual opposing calipers, curved fin vented StopTech two-piece slotted rotors
Power-assist Type - Tandem diaphragm vacuum with zero lost travel
